Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface

I'm Online Chat Now

Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface

Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface
Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface

Large Image :  Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface

Product Details:

Place of Origin: CHINA
Brand Name: YUXING
Certification: CHINA LIGHT INDUSTRY STANDARD
Model Number: CUSTOMIZED

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Packaging Details: STANDARD EXPORT PACKAGE
Delivery Time: 20 WORK DAYS
Payment Terms: T/T, Western Union, MoneyGram
Detailed Product Description
Screen Area: 0.3-3m2 Material: 304 Or 316L Stainless Steel
Basket Type: Hole Type Slot Size: 1-3mm
Computerized: No Condition: New
High Light:

wedge wire screen basket

,

wedge wire basket

The Hole type pressure screen drum / basket made by s.s 304 / s.s316L



The sieve drum is made of stainless steel. There are two types of sieve plate: hole type and slot type, each with different specifications of sieve holes and sieve sizes. Users can choose according to the raw materials and use conditions. The sieve plate adopts drilling (milling seam) and electrolytic polishing processes to meet the requirements of smooth, smooth and non-slurrying.



1. The rod sieve sieve plate is a new generation of plate-type seam sieve plate. The entire plate surface is almost the effective filtering area. It reduces the bearing capacity of the board, which greatly increases the daily production capacity and greatly extends the service life of the screen.

2. The rod sieve sieve plate has high strength, high fatigue strength, and uniform sieve width.

3. The surface of the rod sieve is electrochemically polished without burrs or cotton.

4. The thickness of the wear-resistant layer on the whole surface of the sieve plate reaches 0.2mm, and the surface hardness can reach HV900-1100.



PRESSURE SCREEN IN THE PULP MAKING PROCESS
Model PZSL-1 PZSL-2 PZSL3 PZSL-4 PZSL-5 PZSL-6
Hole size Ø1.1-5mm
Slot size 0.15-1mm
Screen area 0.3 0.5 0.6 1.2 2.0 3.0
Screen basket size Ø406*258mm Ø600*267 Ø600*355 Ø602*634 Ø756*831 Ø1067*1044
Inlet pulp consistency 0.2-6 %
Pulp inlet diameter Ø150 Ø200 Ø200 Ø250 Ø300 Ø400
Pulp outlet diameter Ø150 Ø200 Ø200 Ø250 Ø300 Ø400
Top dump discharging pipe diameter Ø80 Ø80 Ø80 Ø100 Ø100 Ø125
Capacity 10-15 20-30 25-40 40-60 80-100 120-150
Power 18.5-22/4 30-37/4 37-45/4 55-75/4 90-110/4 110-132/4



Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface 0

Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface 1Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface 2Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface 3

Stainless Steel Wedge Wire Screen Basket With Electrochemically Polished Surface 4
