2 Unwinding Rolls Automatic A4 Size Paper Making Machine For Printing Use

Product Summary
Automatic 4 Unwinding Rolls A4 Paper Cutting & Packaging Machine I.Characteristic & Feature: Usage: The Sheet Cutting Machine is suitable to convert jumbo rolls to sheets,specially cutting and slitting 40-120gsm,copy paper,cardboard paper,craft paper,coated paper,laminated craft paper.It is suitable ...
Basic Properties
Place of Origin: China
Brand Name: YUXING
Certification: China light industry standard
Model Number: 1100mm
Trading Properties
Minimum Order Quantity: 1set
Price: USD130000/Set
Payment Terms: L/C, T/T, Western Union,
Supply Ability: 10 sets per 3months
Tags:

paper rewinding machine

paper size press

paper sheet cutting machine
Product Description

Automatic 4 Unwinding Rolls A4 Paper Cutting & Packaging Machine

I.Characteristic & Feature:

Usage: The Sheet Cutting Machine is suitable to convert jumbo rolls to sheets,specially cutting and slitting 40-120gsm,copy paper,cardboard paper,craft paper,coated paper,laminated craft paper.It is suitable for A4 size copy paper sheets cutting.

Characteristic:  The machine adopts servo motor,frequency controlling speed.PLC Control System,including automatic tension control,automatic counting,setting cutting size,automatic stop by setting time&number and other many functions.

Unwinding jumbo roll part use automatic air expanding shaft cylinder control lifter(3 inch)

Unwinding jumbo roll part adopts EPC system,automatic correcting web material position and keeping high cutting precision.

Machine shelf adopt casting steel,guillotine knife use heavy casting structure,traction rollers use static balance processing aluminum rollers.

Automatic stacking&trimming finished sheets,using two stage motors to convey sheets to broadside.The convey broadside model machine can link to automatic packaging machine.

II.Technical Parameter

Model 1100D
Convey Broadside -Four rolls
The max jumbo roll diameter φ1400mm
The max jumbo roll width 1100mm
Cutting size A4
Speed 20-150 cutting times/min
Capacity 6 reams/min
Material GSM 40-120gsm
Precision ±0.2mm
Feeding Roll Four Rolls
Power 18KW
Voltage 380V/50HZ
Weight 10000kg
Dimension(L×W×H) 19000×2500×2200



2 Unwinding Rolls Automatic A4 Size Paper Making Machine For Printing Use2 Unwinding Rolls Automatic A4 Size Paper Making Machine For Printing Use2 Unwinding Rolls Automatic A4 Size Paper Making Machine For Printing Use2 Unwinding Rolls Automatic A4 Size Paper Making Machine For Printing Use2 Unwinding Rolls Automatic A4 Size Paper Making Machine For Printing Use2 Unwinding Rolls Automatic A4 Size Paper Making Machine For Printing Use

  2 Unwinding Rolls Automatic A4 Size Paper Making Machine For Printing Use

Product Details
Highlight:

A4 Size Paper Making Machine

,

2 Unwinding Rolls Paper Making Machine

,

Automatic Paper Cutting Packaging Machine
The Max Jumbo Roll Diameter: 1400mm
The Max Jumbo Roll Width: 1100mm
Cutting Size: A4
Speed: 20-150 Cutting Times
Capacity: 6 Reams/min
Material GSM: 40-120gsm
Precision: ±0.2mm
Feeding Roll: Four Rolls
Power: 18KW
Voltage: 380V/50HZ
Weight: 10000kg
Dimension(L×W×H): 19000×2500×2200
